zmem-org/ZMEM: Extremely fast binary message format with minimal memory overhead and zero copy access

A high-performance binary serialization format with minimal overhead for fixed structs and zero-copy access.

ZMEM (Zero-copy Memory Format) is designed for scenarios where serialization performance is critical: high-frequency trading, game networking, real-time systems, and inter-process communication. Unlike formats that prioritize schema evolution, ZMEM prioritizes raw speed by requiring all communicating parties use identical schemas at compile time.

• Minimal overhead for fixed structs – Direct memcpy serialization with no headers or pointers (only padding to 8-byte boundary)
• Zero-copy deserialization – Access data in-place without parsing or allocation
• Native mutable state – Fixed structs can serve as your application’s data model directly
• 8-byte size alignment (minimum) – All wire sizes are padded to 8 bytes; higher alignment is honored when required (e.g., i128)
• Deterministic output – Identical data always produces identical bytes (content-addressable storage friendly)
• Memory-mapped file support – O(1) random access to any field in large files
• Large data support – 64-bit size headers support documents up to 2^64−1 bytes and arrays up to 2^64−1 elements

This benchmark measures serialization from and deserialization to native C++ types (structs, std::string, std::vector). This is ZMEM’s primary use case.

Throughput in MB/s (higher is better). Benchmarked using Glaze on Apple M1 Max.

This benchmark compares zero-copy field access – reading data directly from the serialized buffer without allocating native types like std::string or std::vector:

ZMEM and FlatBuffers achieve similar zero-copy performance (~14.5 GB/s). Cap’n Proto’s accessor pattern has more overhead (2.8 GB/s).

ZMEM makes an explicit trade-off: no schema evolution in exchange for maximum performance. This is the right choice when:

• All parties are deployed together (IPC, game client/server, embedded systems)
• Performance matters more than independent versioning
• Data is transient (real-time telemetry, frame data, market data)

If you need schema evolution, consider Protocol Buffers, FlatBuffers, BEVE, or Cap’n Proto instead.

With FlatBuffers, you define types in a .fbs schema file and run a code generator. For structs containing strings or vectors, you must use the builder pattern:

// FlatBuffers: Schema file + code generation + builder pattern
flatbuffers::FlatBufferBuilder builder;
auto name = builder.CreateString("Alice");
auto scores = builder.CreateVector(std::vectorfloat>{95.5f, 87.0f, 91.5f});
auto player = CreatePlayer(builder, 42, name, scores);
builder.Finish(player);

With ZMEM (using Glaze), you use your existing C++ structs directly—no schema file, no code generation, no builder:

// ZMEM: Use native C++ types directly
struct Player {
    uint64_t id;
    std::string name;
    std::vectorfloat> scores;
};

Player player{42, "Alice", {95.5f, 87.0f, 91.5f}};
std::string buffer;
glz::write_zmem(player, buffer);  // That's it

ZMEM’s simpler serialization path—no builder objects, no intermediate allocations, no vtable construction—is why it achieves ~3x higher write throughput than FlatBuffers.

version 1.0.0

namespace game

struct Vec3 {
  x::f32
  y::f32
  z::f32
}

struct Player {
  id::u64
  name::str[64]
  position::Vec3
  health::f32 = 100.0
  inventory::[u32]
}

For fixed structs, ZMEM has minimal overhead—just padding to 8-byte boundaries for safe zero-copy access. No headers, vtables, or pointers.

Note: These sizes are illustrative for the specific schemas shown and typical encodings. Actual sizes vary with schema shape and framing.

const MAX_NAME::u32 = 64
const ORIGIN::f32[3] = [0.0, 0.0, 0.0]

type PlayerId = u64
type Name = str[MAX_NAME]
type Color = u8[4]

ZMEM categorizes types into two categories:

Fixed types are trivially copyable and serialize with a direct memcpy. Wire sizes are padded to multiples of 8 bytes (and higher alignment is respected when required):

struct Particle {
    uint64_t id;        // 8 bytes
    float position[3];  // 12 bytes
    float velocity[3];  // 12 bytes
    float mass;         // 4 bytes
    // 4 bytes tail padding (struct alignment = 8)
};
// sizeof(Particle) == 40 bytes (36 data + 4 padding)
// Wire size: 40 bytes (already multiple of 8)
// Serialization: direct memcpy

Structs containing vectors, variable-length strings, or maps use an 8-byte size header plus references for each variable field:

┌──────────────────────────────────────────────────────────────┐
│ [Size: 8 bytes] [Inline Section] [Variable Data Section]     │
└──────────────────────────────────────────────────────────────┘

All wire sizes (fixed and variable) are padded to multiples of 8 bytes, and variable section data is 8-byte aligned, enabling safe zero-copy access via reinterpret_cast. Types with alignment > 8 insert additional padding after headers so the inline section starts at the required alignment.

The benchmarks use Glaze as the ZMEM implementation.

cmake -B build -DCMAKE_BUILD_TYPE=Release
cmake --build build --config Release
./build/zmem_bench

MIT License
