joshuanwalker/Raiders2600: Reverse Engineering Raiders of the Lost Ark for the Atari 2600

Original Game (1982) by Atari, Inc.
Original Designer: Howard Scott Warshaw
Disassembly & Analysis: Dennis Debro & Halkun (That’s me!)

This repository contains the fully reverse-engineered and commented source code for the Atari 2600 classic, Raiders of the Lost Ark.

Unlike a raw disassembly, this project aims to provide a semantic understanding of the game logic. Variables, constants, and subroutines have been renamed and heavily commented to explain how the game works, from the procedural flute music to the complex collision logic in the Map Room.

The project has been reorganized for a clean development workflow:

• src/: Contains the main assembly source (raiders.asm) and header files (tia_constants.h).
• bin/: Contains build tools (DASM) and emulator executable (Stella).
• out/: Destination for compiled binaries (.bin), symbol files (.sym), and listing files (.lst). (auto generated at compile time)
• make.bat: Windows batch script to compile the project.
• run.bat: Windows batch script to launch the compiled game.

• Windows OS
• DASM: dasm.exe must be in the bin/ folder.
• Stella: Stella.exe and SDL2.dll must be in the bin/ folder (optional, for running).

Run the build script from the root directory:
