hervehildenbrand/gtrace: Advanced network path analysis tool with MPLS/ECMP detection, GlobalPing integration, and MTR mode


CI
Go Version
License
Go Report Card
Release
Platform

Advanced network path analysis tool combining local traceroute with GlobalPing’s distributed probe network.

gtrace demo

Feature gtrace mtr traceroute
MPLS label detection Yes No No
ECMP/load balancing detection Yes No No
Active ECMP probing (Paris-style) Yes No No
NAT detection Yes No No
Path MTU discovery Yes No No
GlobalPing integration Yes No No
ASN + geolocation enrichment Yes Partial No
IPv4/IPv6 dual-stack Yes Yes Yes
MTR-style continuous mode Yes Yes No
Latency jitter (StdDev) Yes Yes No
JSON/CSV export Yes Yes No
Built-in self-update Yes No No

  • Multi-Protocol Traceroute: ICMP, UDP, and TCP probing
  • IPv4/IPv6 Support: Dual-stack with -4 and -6 flags
  • MPLS Detection: Extract and display MPLS label stacks from ICMP extensions
  • ECMP Detection: Passive detection of load-balanced paths with multiple IPs per hop
  • Active ECMP Probing: Paris traceroute-style flow variation to actively discover ECMP paths
  • NAT Detection: Identify NAT devices along the path via response TTL analysis
  • Path MTU Discovery: Discover per-hop MTU using Don’t Fragment bit and ICMP feedback
  • Rich Enrichment: ASN lookup, reverse DNS, geolocation, IX detection
  • MTR Mode: Continuous monitoring with real-time statistics including latency jitter (StdDev)
  • GlobalPing Integration: Run traces from 500+ global probe locations
  • Export Formats: JSON, CSV, and text output

Download the latest release for your platform from the Releases page.

Available for Linux, macOS, and Windows (amd64 and arm64).

# Example: Linux amd64 (replace VERSION with the desired release, e.g. 0.3.3)
curl -LO https://github.com/hervehildenbrand/gtrace/releases/download/vVERSION/gtrace_VERSION_linux_amd64.tar.gz
tar xzf gtrace_VERSION_linux_amd64.tar.gz
sudo mv gtrace /usr/local/bin/
go install github.com/hervehildenbrand/gtrace/cmd/gtrace@latest
git clone https://github.com/hervehildenbrand/gtrace.git
cd gtrace
go build -o gtrace ./cmd/gtrace
# Basic ICMP traceroute
sudo gtrace 8.8.8.8 --simple

# UDP traceroute with ECMP detection
sudo gtrace cloudflare.com --simple --protocol udp --packets 6

# Active ECMP probing (Paris traceroute-style)
sudo gtrace cloudflare.com --simple --protocol udp --ecmp-flows 8

# TCP traceroute to specific port
sudo gtrace example.com --simple --protocol tcp --port 443

# NAT detection
sudo gtrace 8.8.8.8 --simple --detect-nat

# Path MTU discovery
sudo gtrace 8.8.8.8 --simple --discover-mtu --probe-size 1500

# MTR-style continuous monitoring
sudo gtrace 8.8.8.8

# Compare local and remote traces
sudo gtrace 8.8.8.8 --compare --from "New York,London"

# IPv6 traceroute
sudo gtrace -6 google.com --simple

# Compare IPv6 local vs remote
sudo gtrace -6 google.com --compare --from Paris

Flag Description Default
-4, --ipv4 Force IPv4 only false
-6, --ipv6 Force IPv6 only false
--protocol Protocol: icmp, udp, tcp icmp
--port Target port (TCP/UDP) 33434
--max-hops Maximum TTL 30
--packets Probes per hop 3
--timeout Per-hop timeout 500ms
--simple Simple output (no TUI) false

Flag Description Default
--detect-nat Enable NAT detection via TTL analysis false
--ecmp-flows ECMP flow variations per hop (0=disabled) 0
--discover-mtu Enable Path MTU Discovery false
--probe-size Probe packet size in bytes 64

Flag Description Default
--interval Time between cycles 1s
--cycles Number of cycles (0=infinite) 0

Keyboard shortcuts in MTR mode:

  • p – Pause/Resume
  • r – Reset statistics
  • n – Toggle DNS/IP display
  • q – Quit

Flag Description
--from Probe locations, comma-separated (max 5)
--compare Compare local trace with remote probes
--api-key GlobalPing API key for higher rate limits

Flag Description
-o, --output Export to file (format auto-detected from extension)
--format Explicit format: json, csv, text (or txt)

Flag Description
--offline Use only local GeoIP databases
--db-status Show GeoIP database status
--download-db Instructions to download GeoIP databases

gtrace checks for new versions on startup and displays a notification after the trace completes. To upgrade in place:

gtrace upgrade          # Interactive prompt
gtrace upgrade --force  # Non-interactive

Environment Variable Description
GTRACE_NO_UPDATE_CHECK=1 Disable the automatic update check on startup

sudo gtrace www.internet2.edu --simple

Output shows MPLS labels on backbone hops:

 8  129.250.2.106  [AS2914]  202ms  [MPLS: L=309833 E=0 S=1 TTL=1]
 9  129.250.6.6    [AS2914]  79ms   [MPLS: L=36001 E=0 S=1 TTL=1]

Detect Load Balancing (ECMP)

# Passive detection: send multiple probes and observe path divergence
sudo gtrace cloudflare.com --simple --protocol udp --packets 8

# Active probing: Paris traceroute-style flow variation
sudo gtrace google.com --simple --protocol udp --ecmp-flows 8

Multiple IPs at the same hop indicate ECMP:

 6  72.14.202.232  72.14.205.190  193.251.255.104  72.14.204.184  [AS15169]  3.44ms

sudo gtrace 8.8.8.8 --simple --detect-nat

NAT devices are identified by TTL anomalies in ICMP responses:

 3  10.0.0.1  [AS3215]  5.42ms 4.89ms 5.01ms  [NAT]
 7  72.14.236.73  [AS15169]  8.21ms 7.98ms 8.44ms  [NAT]

sudo gtrace 8.8.8.8 --simple --discover-mtu --probe-size 1500 --protocol udp

Discovers the MTU along the path using the Don’t Fragment bit:

 1  192.168.1.1  0.87ms 0.76ms 0.60ms
 2  80.10.255.25  [AS3215]  1.57ms 1.05ms 1.81ms  [MTU:1500]

When the probe size exceeds the path MTU, EMSGSIZE is reported locally:

# Force IPv6
sudo gtrace -6 google.com --simple

# Compare IPv6 paths from different locations
sudo gtrace -6 cloudflare.com --compare --from "Frankfurt,Singapore"
sudo gtrace 8.8.8.8 --simple -o trace.json

JSON includes full hop data with ASN, geolocation, timing, and detection results:

{
  "target": "8.8.8.8",
  "hops": [
    {
      "ttl": 1,
      "ip": "192.168.1.1",
      "avgRtt": 0.5,
      "lossPercent": 0,
      "nat": true,
      "mtu": 1500
    }
  ]
}
# Compare against a single remote location
sudo gtrace 8.8.8.8 --compare --from Paris

# Compare against multiple remote locations (up to 5)
sudo gtrace 8.8.8.8 --compare --from "Paris,Tokyo"

Each remote location produces its own side-by-side comparison against the local trace, separated by ===. Column headers show the actual probe location (e.g. “Paris, FR, OVH SAS”).

gtrace/
├── cmd/gtrace/          # CLI entry point
├── internal/
│   ├── trace/           # Traceroute engines (ICMP, UDP, TCP)
│   ├── display/         # TUI and simple output renderers
│   ├── enrich/          # ASN, geo, rDNS enrichment
│   ├── export/          # JSON, CSV, text exporters
│   ├── globalping/      # GlobalPing API client
│   ├── monitor/         # Route change detection
│   └── update/          # Auto-update and self-upgrade
└── pkg/hop/             # Hop data structures
  • Go 1.24+
  • Root/sudo privileges for raw socket access
  • Optional: MaxMind GeoIP databases for offline geolocation

MIT
