MQTT Monitor is an Android MQTT client focused on message monitoring and notification delivery from user-managed brokers.

  • Application ID: org.archuser.mqttnotify
  • Current Version: 1.1.0 (versionCode 3)
  • Language: Kotlin
  • UI: Jetpack Compose
  • Min SDK: 26
  • Target/Compile SDK: 36
  • Broker management (create, edit, delete, activate/deactivate)
  • Broker validation (connection test required before save)
  • MQTT protocol support: 3.1.1 and 5.0
  • Optional TLS and username/password authentication
  • Topic subscription management (QoS, per-topic notifications, retained-as-new behavior)
  • Local message persistence and per-topic counters
  • Per-message read/unread state and per-message deletion
  • Message Feed controls for Read all, Mark read, and Mark unread
  • Unread messages indicated with a dot marker on the message card
  • Global notification mute with duration selection
  • Material You enable/disable setting
  • Diagnostics/event log view

Active While Visible (VISIBLE_ONLY)

  • MQTT connection is maintained while UI is visible.
  • Connection is dropped when app is backgrounded.

Persistent Foreground (PERSISTENT_FOREGROUND)

  • MQTT connection is maintained by a foreground service.
  • Persistent notification is required while active.
  • Message alerts use a dedicated high-importance channel.
  • Foreground service status uses a separate low-importance channel.
  • Global mute affects notifications only; ingestion and storage continue.
  • Android system notification settings remain authoritative for final alert behavior.

The following screenshots document the current UI flows and states.

Dashboard

Dashboard

Broker List

Broker List

Broker Editor

Broker Editor

Topic Configuration

Topic Configuration

Message Feed

Message Feed

Settings

Settings

Notifications

Notifications

Main source root: app/src/main/java/org/archuser/mqttnotify/

  • core/: utility abstractions (time, dispatchers, topic matching)
  • connection/: connection coordinator/state logic
  • data/local/: Room entities, DAO interfaces, database
  • data/mqtt/: MQTT adapter and connection test implementation
  • data/repo/: repository implementations
  • data/security/: encrypted credential storage
  • domain/model/: app domain models
  • domain/repo/: repository contracts
  • notifications/: notification channels and dispatch
  • service/: persistent foreground service
  • ui/navigation/: Compose navigation graph
  • ui/screen/: Compose screen components
  • ui/viewmodel/: state/view logic
  • di/: Hilt module bindings

Room tables:

  • brokers
  • topic_subscriptions
  • messages
  • topic_counters
  • retention_policies
  • app_state

Declared in app/src/main/AndroidManifest.xml:

  • android.permission.INTERNET
  • android.permission.ACCESS_NETWORK_STATE
  • android.permission.POST_NOTIFICATIONS
  • android.permission.FOREGROUND_SERVICE
  • android.permission.FOREGROUND_SERVICE_DATA_SYNC

Build debug APK:

./gradlew :app:assembleDebug

Run unit tests:

./gradlew :app:testDebugUnitTest

Run standard local validation:

./gradlew :app:testDebugUnitTest :app:assembleDebug
  • Background message delivery is best-effort and platform-dependent. It may require disabling battery optimizations.
  • Foreground mode still depends on network availability and broker uptime.
  • Existing notification channel preferences may persist across reinstalls depending on device behavior.

Copyright (C) 2026 firebadnofire

This project is licensed under the GNU General Public License v3.0.

  • SPDX license identifier: GPL-3.0-only
  • Full license text: LICENSE
  • Warranty disclaimer: provided by GPLv3 terms; software is distributed without warranty.
